Canon PIXMA G540-Wireless Photo Printer, (1YR WRTY)

Single function printer with six refillable dye-based ink tanks, for high quality photo printing with the ability to produce high volumes at extremely low cost.

Photo printing

Top-quality photo printing with enhanced colour gamut.

High page yield

Print up to 3,800 4x6 photos from a set of bottles

TECHNICAL SPECIFICATIONS

General Specifications

Functions

• Wi-Fi, Print & Cloud

Printer Specifications

Print Resolution

• Up to 4800 x 1200 dpi1

Print Technology

• 2 FINE Print Heads (Left : BK/R/Gy, Right : C/M/Y)
• Refillable ink tank printer

Mono Print Speed

• approx. 3.9 ipm2

Colour Print Speed

• approx. 3.9 ipm3

Photo Print Speed

• Borderless 4" x 6" (10x15cm) : Approx. 47 seconds4

Borderless Printing

• Yes
• A4, LTR, 4"" x 6"" (10x15cm), 5"" x 7"" (13x18cm), 7"" x 10"" (18x25cm), 8"" x 10"" (20x25cm), Square 5"" x 5"" (127mm x 127mm), Square 3.5"" x 3.5"" (89 mm x 89 mm), Card Size 55mm x 91 mm (2.17"" x 3.58"")5

Two Sided Printing

• Manual operation

Consumables and Yields

Standard Ink Bottles

• GI-43
• GI-43
• GI-43
• GI-43
• GI-43
• GI-43

Maintenance Cartridge

• MC-G02 (User Replaceable)

Bottle Yield (Plain Paper)

• A4 colour documents printing6
• Black: 3,700 pages
• Colour: 8,000 pages
• Estimated supplemental yield

Bottle Yield (Photo Paper)

• 4"" x 6"" (10x15cm) colour photo printing7
• Colour: 3,800 photos
• Estimated supplemental yield

Paper Support

Paper Types

• Plain Paper
• Photo Paper Pro Luster (LU-101),
• Photo Paper Plus Glossy II (PP-201)
• Matte Photo Paper (MP-101),
• Glossy Photo Paper ""Everyday Use"" (GP-501)
• High Resolution Paper (HR-101N),
• Photo Paper Plus Semi-gloss (SG-201),
• Premium Fine Art Rough
• Restickable Photo Paper(RP-101)
• Magnetic Photo Paper(MG-101)
• Dark Fabric Iron on Transfers (DF-101),
• Light Fabric Iron on Transfers (LF-101),
• Double sided Matte Paper (MP-101D)
• Greeting Card (manufactured by Avery and RedRiverPaper),
• Cardstock (manufactured by Neenah Paper and INKPRESS),
• Canon Red Label Superior(WOP111)
• Canon Oce Office Colour Paper(SAT213)

Maximum Paper Input

• Rear Tray: Plain paper: 64 - 105 g/m² (100 sheets) or supported genuine Canon papers
• Please refer to online manual for a detailed list of paper load limits, which will vary depending on media type and page size selected.

Paper Sizes

• A4, A5, B5,A6, LTR, LGL, 4"" x 6"" (10x15cm),  5"" x 7"" (13x18cm), 7"" x 10"" (18x25cm), 8"" x 10"" (20x25cm), Square 5"" x 5"" (127mm x 127mm), Square 3.5"" x 3.5"" (89 mm x 89 mm), Card Size 55mm x 91 mm (2.17""x3.58"")
• Envelopes(DL, COM10, C5, Monarch),
• [Custom size]
• width 55 - 216 mm, length 89 - 1200 mm

Paper Weight

• Rear Tray: Plain paper: 64 - 105 g/m² or supported genuine Canon papers
• Photo paper: max paper weight : approx. 275 g/m² or supported genuine Canon papers

Interface

Display Type & Size

• Full Dot LCD (Monochrome)

Connectivity

Standard Interface

• Hi-Speed USB (USB B Port)
• Wi-Fi: IEEE802.11 b/g/n/a8
• Wi-Fi Security: WPA-PSK, WPA2-PSK, WEP, Administration password
• Wireless LAN Frequency Band: 2.4 GHz
• PictBridge Wi-Fi9

Mobile Apps

• Canon PRINT Inkjet/SELPHY app10
• Creative Park app11
• Easy-PhotoPrint Editor app12

Printer Features

• Easy-PhotoPrint Editor Software13
• PIXMA Cloud Link (print - from smartphone or tablet only)14
• Canon Print Service Plugin (Android)15
• Apple AirPrint16
• Wireless Direct17
• Mopria (Android)18

Smart Assistant & Automation Support

• Amazon Alexa™19
• Google Assistant™20

Software

Supported Operating Systems

• Windows 10、Windows 8.1、Windows 7 SP1
• Operation can only be guaranteed on a PC with pre-installed Windows 7or later.
• Printer driver and IJ Printer Assistant Tool are available with following OS.
• Windows Server 2008 R2 SP1、Windows Server 2012 R2、Windows Server 2016、Windows Server 2019
• Mac: OS X 10.12.6 ～ macOS 10.15
• Chrome OS

Mobile Operating Systems: iOS®, iPadOS, Android™21

• *OS compatibility confirmed at time of launch, please check the Canon Download Centre for support of subsequently released OS’s for this product.

Minimum System Requirements

• Windows: 1.5GB or more
• Note: for bundled software installation. The necessary amount of hard disk space required.

Software Included

• Printer Driver
• IJ Printer Assistant Tool
• Easy-PhotoPrint Editor (download)

Physical Features

Weight

• approx. 5.1Kg

Dimensions (W x D x H)

• approx. 445 x 340 x 136mm (trays retracted)
• approx. 445 x 564 x 249mm (trays extended)

Acoustic Noise Levels

• approx. 50.5dB(A)22

Recommended Operating Environment

• Temperature: 5-35°C, Humidity: 10-90%RH (no dew condensation)

Power Source

• AC 100-240V, 50/60Hz

Power Consumption

• Off: Approx. 0.2W
• Standby (USB connection to PC): Approx. 0.6W
• Standby (all ports connected): Approx. 1.2W
• Time to enter Standby mode: 4 minutes 4sec*
• Printing: Approx. 14W
• *The wait time for standby cannot be changed

Typical Electricity Consumption

• 0.18 kWh
