HP UltraSlim Docking Station For Elitebooks, (1YR WRTY)

Designed exclusively for ultraslim HP EliteBook Notebook PCs (up to G6 generation), the HP UltraSlim Docking Station expands display, network, and device connectivity so you can be more productive throughout the day—all through a simple one-click slide-in side dock.

Features

Four USB 3.0 ports offer high-speed connectivity to the USB devices you use most. USB 3.0 reduces the time required for data transmission (vs. USB 2.0), is backward compatible with USB 2.0, and is bi-directional.
Get high-speed connectivity to the USB devices you use most with four USB 3.0 ports, which reduce the time required for data transmission (vs. USB 2.0), are backward compatible with USB 2.0, and bi-directional.
Secure the connected notebook to the dock with the optional HP Docking Station Cable Lock (sold separately).

Compatible with (up to G6 generation) HP EliteBook Folio 1020 G1; HP EliteBook Folio 1040 G1, G3; HP EliteBook 1040 G2; HP EliteBook Revolve 810 G1, G3; HP EliteBook 820 G1, G2, G3, G4; HP EliteBook 840 & 850 G1, G2, G3, G4, G5, G6; HP EliteBook 830 G5, G6; HP EliteBook 720, 740, 750 G1, G2; HP EliteBook 725 G3, G4, G5; HP EliteBook 745, 755 G3, G4, G5, G6; HP EliteBook 735 G5, G6; HP ProBook 640, 650 G2, G3, G4, G5; HP ProBook 645 G2, G3, G4, G5; HP ProBook 655 G2, G3, G4; HP EliteBook Folio 9480m, 9470m; HP ZBook 14u G4, G5, G6; HP ZBook 15u G3, G4, G5, G6

Front side

Figure : Fronts

Item Number	Component
1	Docking posts
2	Locking mechanism (lock not included)
3	Side docking connector

Rear side

Figure : Rear

Item Number	Component
1	Docking station cable lock slot (lock not included)
2	Connection button
3	Connect light
4	Lock slot (lock not included)
5	Docking station cable lock slot (lock not included)
6	VGA port
7	LAN/Ethernet port
8	DisplayPort 1.2
9	USB 3.0 ports (3)
10	USB 3.0 charging port (1)
11	Power connector
12	Line in jack
13	Line out jack
