Jbl Bar 5.1 Soundbar with True Wireless Surround Speakers - Black (1 YR WRTY)

The impressive JBL Bar 5.1 Surround delivers the ultimate home cinematic experience. Bring everything you watch to life with 550 Watts of power and a 10’’ subwoofer: the driving bass of an action movie, the tension of a thriller or the beauty of a nature documentary. Built-in Chromecast and Airplay 2 lets you stream and manage online content, and Bluetooth means your streamed music sounds great, too. Amazing surround sound comes from JBL MultiBeam™ technology. JBL has powered the world’s movie theatres for more than 75 years. Now you can bring that power home.

Features

• True HDMI 4K Pass-through: The best 4K video resolution deserves the best sound to go with it. Your TV and the JBL Bar 5.1 Surround are the ultimate power couple.
• Stream it all: Not in the mood for a film? No problem. With the JBL Bar 5.1 Surround, you can also enjoy wireless music streaming via Bluetooth from your mobile or tablet.

General Specifications

• Model Bar 5.1 CNTR (Soundbar Unit), BAR 5.1 SUB (Subwoofer Unit)
• Power supply 100 - 240V AC, ~ 50/60Hz
• Soundbar output power (Max. @THD 1%) 5 x 50W
• Subwoofer output power (Max. @THD 1%) 300W
• standby power <0.5W
• networked standby power <2.0W
• Operating temperature 0°C - 45°C
• BAR 5.1 SURROUND is in compliance with European Commission Regulation (EC) No 1275/2008 and (EU) No 801/2013.
• Off Mode N/A
• Network Standby <2.0W
• Time to standby <20minutes

Audio Specifications

• Total speaker power output (Max. @THD 1%) 550W
• Max SPL 103dB
• Frequency response 40Hz - 20KHz
• Audio inputs 1 Optical, Bluetooth, USB (USB playback is available in US version. For other versions, USB is for Service only.)
• MP3 Codec MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
• MP3 sampling rate 16KHz - 48 KHz
• MP3 bitrate 80kbps - 320kbps

Dimensions

• Soundbar transducer 5 x 4690” racetrack drivers +2 x 1.25” side-firing tweeters
• Subwoofer transducer 10”
• Dimensions (W x H x D) 1018 x 58 x 100mm / 40” x 2.28” x 3.94” (Soundbar); 305 x 440 x 305mm / 12” x 17.3” x 12” (Subwoofer)
• Weight 2.85KG (Soundbar); 10.62Kg (Subwoofer)

Control & Connection Specs

• USB port Type A
• USB rating 5V DC, 0.5A
• Supporting file format mp3, wav
• Bluetooth version 4.2
• Bluetooth profile A2DP V1.3, AVRCP V1.5
• Bluetooth frequency range 2402MHz - 2480MHz
• Bluetooth Max. transmitting power <11dBm (EIRP)
• Modulation Type GFSK, π/4 DQPSK, 8DPSK
• Wi-Fi network IEEE 802.11 a/b/g/n/ac (2.4GHz/5GHz)
• 2.4G Wi-Fi frequency range 2412 – 2472MHz (2.4GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)
• 2.4G Wi-Fi Max. transmitting power <20dBm
• Modulation Type   DBPSK, DQPSK, CCK, QPSK, BPSK, 16QAM, 64QAM
• 5G Wi-Fi frequency range 5.15 - 5.35GHz, 5.725 - 5.825GHz
• 5G Wi-Fi Max. transmitting power <22dBm
• Modulation Type QPSK, BPSK, 16QAM, 64QAM, 256QAM
• 5G Wireless frequency range 5161.35 - 5245.35MHz, 5736.35 - 5820.35MHz
• 5G Max. transmitting power <9dBm (EIRP)
• Modulation Type  π/4 DQPSK
