Share this product
Brand: One | Similar products from One
KSh 36,400
KSh 42,00013%
Few units left
+ shipping from KSh 90 to CBD - UON/Globe/Koja/River Road
0 out of 5
(No ratings available)Promotions
Delivery & Returns
Choose your location
Pickup Station
Delivery Fees KSh 90
Ready for pickup between 16 September and 18 September if you place your order within the next 12hrs 43mins
Door Delivery
Delivery Fees KSh 200
Ready for delivery between 16 September and 18 September if you place your order within the next 12hrs 43mins
Return Policy
Easy Return, Quick Refund.Details
Seller Information
Estrex Solar
New Seller
Be the first to follow
Seller Performance
This seller does not have enough history for us to evaluate his performance yet
Product details
Specifications
Key Features
| Rated Power | 3.2KW | |
| Line Mode Specifications | ||
| Input Voltage Waveform | Sinusoidal (utility or generator) | |
| Nominal Input Voltage | 230VAC | |
| Low Loss Voltage | 170Vac±7V(UPS);90Vac±7V (Appliances) | |
| Low Loss Return Voltage | 180Vac±7V(UPS);100Vac±7V(Appliances) | |
| High Loss Voltage | 280Vac±7V | |
| High Loss Return Voltage | 270Vac±7V | |
| Max AC Input Voltage | 300Vac | |
| Nominal Input Frequency | 50Hz/60Hz (Auto detection) | |
| Low Loss Frequency | 40+1Hz | |
| Low Loss Return Frequency | 42±1Hz | |
| High Loss Frequency | 65+1Hz | |
| High Loss Return Frequency | 63+1Hz | |
| Output Short Circuit Protection | Circuit Breaker | |
| Efficiency (Line Mode) | >95%( Rated R load, battery full charged ) | |
| Transfer Time | 10ms typical (UPS);20ms typical (Appliances) | |
| Inverter Mode Specifications | ||
| Output Voltage Waveform | Pure Sine Wave | |
| Output Voltage Regulation | 230Vac±5% | |
| Output Frequency | 50Hz | |
| Peak Efficiency | 94% | |
| Overload Protection | 5s@≥150% load; 10s@110%~150% load | |
| Surge Capacity | 2* rated power for 5 seconds | |
| Nominal DC Input Voltage | 24Vdc | |
| Cold Start Voltage | 23.0Vdc | |
| Low DC Warning Voltage @ load < 50% @ load ≥ 50% | 22.0Vdc 21.0Vdc | |
| Low DC Warning Return Voltage @ load < 50% @ load ≥ 50% | 22.5Vdc 22.0Vdc | |
| Low DC Cut-off Voltage @ load < 50% @ load ≥ 50% | 20.5Vdc 20.0vdc | |
| High DC Recovery Voltage | 32Vdc | |
| High DC Cut-off Voltage | 33Vdc | |
| No Load Power Consumption | <35W | |
| Charge Mode Specifications | ||
| Charging Algorithm | 3-Step | |
| AC Charging Current (Max) | 60 Amp(@VP=230Vac) | |
| Flooded Battery | 29.2 | |
| AGM /Gel Battery | 28.2 | |
| Floating Charging Voltage | 27Vdc | |
| MPPT Solar Charging Mode | ||
| INVERTER MODEL | 3KW-24V | |
| Max. PV Array Power | 3000W | |
| Nominal Pv Voltage | 240Vdc | |
| PV Array MPPT Voltage Range | 30~430Vdc | |
| Max.PV Array Open Circuit Voltage | 450Vdc | |
| Max Charging Current (AC charger plus solar charger) | 80Amp | |
What’s in the box
1x hybrid inverter
Specifications
- SKU: ON724EA5KPAUCNAFAMZ
- Model: 3KW-24V
- Size (L x W x H cm): 40.5x30.3x10.7
- Weight (kg): 6.18
Customer Feedback
This product has no ratings yet.
/product/37/1036523/1.jpg?6527)
One Solar Hybrid Inverter 3kW 3kVA 24V with 80A MPPT Controller
KSh 36,400
KSh 42,00013%
