Name: Solar PWM Charge Controller 12V/24V 10A 20A 30A 40A 50A 60A
Brand: Solarmax
Price: 900.00 KES
Availability: InStock

Home Electronics Accessories GadgetsSolar PWM Charge Controller 12V/24V 10A 20A 30A 40A 50A 60A

Delivery & Returns

Delivery Fees KSh 90

Ready for pickup between 16 September and 18 September if you place your order within the next 10hrs 59mins

Delivery Fees KSh 200

Ready for delivery between 16 September and 18 September if you place your order within the next 10hrs 59mins

Easy Return, Quick Refund.Details

Seller Information

Estrex Solar

New Seller

Be the first to follow

This seller does not have enough history for us to evaluate his performance yet

Rated Charge Current	10A	20A	30A	40A	50A	60A
System voltage	50V
Maximum PV open circuit voltage	≤30mA
Loop voltage drop	≤0.3V
USB Output	5V/2A×4
Temperature compensation	-4mV/℃/2V(25℃)
Working temperature range	-20℃~+50℃
Protection category	IP32
Humidity	95%,no-condensing
Terminals	8AWG/10mm2		8AWG/16mm2		4AWG/25mm2
Mounting hole size	158×68mm Φ 6mm		190×69mm Φ 5mm		190×104mm Φ 5mm
Product size	168×88×36mm		200×106×47mm		200×131.6×62mm
Weight	0.22Kg		0.4Kg		0.73Kg	0.75Kg
