Satlink WS-6933 -S2 FTA C&KU Band Digital Satellite Signal Finder

Package Included:
1 x Signal Finder Meter
1 x Protective Rubber Cover
1 x Power Adapter
1 x USB Cable
1 x Lanyard
1 x User Manual










Specification:
Size: Approx. 7.7x17x3.5cm/ 3.03x6.69x1.37"
Plug Type: EU plug (sent with an adapter according your country)
Input Frequency: 950~2150MHz
Input Level: -65~ -25dBm
Band Switch Control: 22KHz
LNB Supply: 13v/18v, IMAX.300mA
Demodulation Type: QPSK/ 8OSK/ 16APSK/ 32APSK
Symbol Rate: 2＜Rs＜45Mband(SCPC/MCPC)
LCD Type: TFT Positive transflective
Number Of Dots: 240(RGB)*320
Active Area(WxH): 36.72x48.96mm2
Connector: USB
Data Protocol: USB to RS-232
Li-ion Battery: 7.4v/ 800mah
Output: 12V/ 1A
Input: 100-240V AC, 50/60Hz
Power Consumption: MAX. 5W
The device finds the desired satellite in seconds
The rear flashlight function can provide lighting
The Satlink WS-6933 HD is a compact Satellliten Finder
The device has a static NIT recognition for safe identify a received satellite signal
If a satellite found an audible sound - signal and the measured values are displayed
Satellite search, the satellite dish can be in contrast to traditional instruments turned very quickly
