Indicators

Choose the indicator type that matches your goal: use dial indicators for precise measurements, magnetic gas level indicators for level sensing, or indicator lights for a visible status signal. Then check panel fit by selecting the right cutout size (22 mm or 10 mm) and mounting method (screw terminals or lug terminals). Consider the environment and visibility, including color options for lights and the required wiring. For a balanced setup, pair the indicator type with appropriate accessories from the generic indicators catalog.

Panel cutout size and terminal type determine fit and wiring when choosing indicators. In our range you’ll find 22 mm indicators with screw terminals and 10 mm indicators with lug terminals, so pick the combination that matches your panel and wiring harness. This choice also influences how easily you can mount and service the unit in tight spaces. Align the size and connection type with your application, whether you’re using dial indicators, magnetic gas level indicators, or indicator lights.

In a professional workshop, prefer durable indicator lights with secure mounting, clear color coding, and reliable power options for daily use, alongside precision dial indicators for measurements. For a DIY hobbyist setup, start with versatile indicator lights in common panel sizes and a basic magnetic gas level indicator for level monitoring. This way you cover both status signaling and simple measurement tasks without overcomplicating the workspace.

Mount indicators using the appropriate panel cutout and secure terminals to ensure reliable operation. Keep lenses and housings clean and dry to maintain visibility, and periodically check calibration for dial indicators. For electronic indicators and indicator lights, inspect connections for signs of wear and replace any damaged parts promptly to avoid false readings or mis signals.

Start by confirming the supply voltage matches the indicator's requirements, as some lights and turn signals use 12 V systems. Choose the right terminal type (screw or lug) based on your panel and wiring harness, and plan for proper wiring protection and routing. For dial indicators, consider mechanical stability and the need for occasional recalibration alongside electrical indicators in mixed panels. This ensures safe, reliable operation across devices from dial indicators to indicator lights and turn-signal indicators.

Indicator lights are available in colors such as green, orange, blue, and yellow, with compatible panel sizes like 22 mm or 10 mm and varied terminal options. Use color coding to communicate different statuses clearly on a control panel, for example green for active, yellow for caution, and blue for information. Verify that the color choices you pick are supported by the indicator lights in your catalog and match your existing panel design.
